4-281025: Siegmund 1,200x800mm "BASIC" System 28 Welding Table

4-281025: Siegmund 1,200x800mm "BASIC" System 28 Welding Table

Availability: Pre-Order
$1,359 $1,698
Successful pre-order.Thanks for contacting us!

The System 28 "BASIC" Welding Table Series was created with Versatility and Strength in mind.

Welding Table Specs and Features:

  • Overall Tabletop Size: 1,200 x 800 x 25mm (47.24" x 31.5" x 0.98")
  • Welding Table Series: Basic Series
  • Welding Table Material Thickness: Approx. 24.5 – 27mm (0.96" - 1.06")
  • Welding Table Material Type and Finish: High Quality S355J2+N Steel
  • Official Welding Table Part No.: 4-281025
  • Borehole: Ø 28mm (1.10")
  • Grid: Grid lines in a distance of 100x100mm (3.96" x 3.96") help you to arrange your accessories.
  • Approximate Table Weight: 575 lbs. / 260 kg.
  • Ribbing and Holes: The desk top has no ribbing and is milled on 5 sides. The table has thread holes on all sides. (It is possible to fixate stops on the sides of the table in distances of 200 mm by M12 thread holes.)

The video below displays the Toughness and Reliability of our System 28 Professional Extreme Series Welding Tables. Showing why they're completely unsurpassable in Strength.

Welding Table Leg Options(Part Numbers, Specs and Pricing):

  • Standard Siegmund Leg(s)
    • Item No.: 161856
    • Leg Height: 32" / 815mm
    • Table Height: 33.4" / 850mm
    • Fine Adjustment: 1.96" / 50mm
    • Capacity Per Table Leg: 2,200 lbs.
    • Cost Per Leg: $0 (Included with Welding Table as a Standard)
    • Cost Per 4 Leg Set: $0 (Included with Welding Table as a Standard)
  • Height Adjustable Siegmund Leg(s)
    • Item No.: 4-160877.XX
    • Leg Height (Adjustable): 21.65" - 37.4" / 550mm - 950mm
    • Table Height (Adjustable): 23.6" - 39.37" / 600mm - 1,000mm
    • Fine Adjustment: 1.57" / 40mm
    • Capacity Per Table Leg: 2,200 lbs.
    • Cost Per Leg: $76
    • Cost Per 4 Leg Set: $304
  • Siegmund Leg(s) with Casters and Locking Brakes
    • Item No.: 4-161855.XX
    • Leg Height: 32" / 815mm
    • Table Height: 33.4" / 850mm
    • Fine Adjustment: 1.96" / 50mm
    • Capacity Per Table Leg: 440 lbs.
    • Cost Per Leg: $85
    • Cost Per 4 Leg Set: $340
  • Height Adjustable Siegmund Leg(s) with Casters and Locking Brakes
    • Item No.: 4-160879.XX
    • Leg Height (Adjustable): 23.6" - 35.4" / 600mm - 900mm
    • Table Height (Adjustable): 25.6" - 37.4" / 650mm - 950mm
    • Fine Adjustment: 1.57" / 40mm
    • Capacity Per Table Leg: 440 lbs.
    • Cost Per Leg: $127
    • Cost Per 4 Leg Set: $508
  • Siegmund Leg(s) for Floor Anchoring
    • Item No.: 4-160874.XX
    • Leg Height: 32" / 815mm
    • Table Height: 33.4" / 850mm
    • Fine Adjustment: 1.96" / 50mm
    • Capacity Per Table Leg: 2,200 lbs.
    • Cost Per Leg: $89
    • Cost Per 4 Leg Set: $356
