2-160138: 500 GK Left Stop and Clamping Square (Aluminum/Titanium)

2-160138: 500 GK Left Stop and Clamping Square (Aluminum/Titanium)

Availability: In Stock
$326 $378
Successful pre-order.Thanks for contacting us!

The Siegmund 500 FK Left Stop and Clamping Square (Aluminum/Titanium), facilitates a multitude of clamping options, due to its three-dimensionality. It is especially designed for working with heavy parts, and can be used as a stop as well as a table extension. Stop and Clamping Squares are manufactured using an aluminum-titanium alloy, to reach maximum stability. Ordering in pairs is recommended.

Aluminum-Titanium: We use this lightweight and high-strength material for weight reasons for some large stop and clamping squares. However, the hardness of nitrided cast steel can not be achieved here.

Specs and Features:
- Item No. 2-160138
- Aluminum/Titanium
- Stop on Left
- Standard mm Fine Scale
- Length: 195mm (7.67'')
- Width: 49mm (1.92'')
- Height: 500mm (19.68'')
- Material Thickness: 14mm (0.55'')
- Weight: 11.7 Ibs.
