The Siegmund Square U-Shape 200x200x150 Plasma Nitrided provides reliable stability for vertical setups and extensions between Siegmund welding tables. Compact yet extremely rigid, it offers consistent alignment and strong load-bearing performance for modular welding configurations.
- Made from high-strength steel and plasma nitrided for durability and corrosion resistance.
- Ideal for connecting two Siegmund System 22 tables or extending the workspace vertically.
- Features diagonal hole arrangement for flexible clamping and fixture options.
- Includes grid lines with 100mm (3.94" Inches) spacing for precise orientation.
- Requires table leg support when used for extensions longer than 1,000mm (39.37" Inches).
- Mounting holes provided on 500mm (19.69" Inches) and larger U-shaped squares.
Key Features:
- Durable plasma-nitrided finish resists wear and weld spatter.
- Diagonal bore pattern enhances flexibility in clamping arrangements.
- Provides secure table extension and vertical mounting capability.
- Compatible with Siegmund System 22 fixtures and accessories.
- Delivers accurate 90° alignment for heavy-duty applications.
Specifications:
- Series: Siegmund System 22 Metric Series
- Length: 200mm (7.87" Inches)
- Width: 200mm (7.87" Inches)
- Height: 150mm (5.91" Inches)
- Material Thickness: 18mm (0.71" Inches)
- Material: Plasma Nitrided Steel
- Weight: 41.89 lbs. (19 kg.)
Common Uses:
The Siegmund 2-220350.P Square U-Shape provides rigid support for table extensions and vertical configurations. It allows fabricators to link tables, add fixture height, or build multi-level setups with exact alignment. Frequently used to stabilize assemblies or extend the System 22 work surface beyond 1,000mm, it ensures accurate, repeatable performance in precision welding and fabrication environments.
