The Siegmund Square U-Shape with elongated hole provides enhanced flexibility for fixturing setups by combining standard system boreholes with elongated slots for adjustable positioning. With its nitrided finish and heavy-duty steel construction, it ensures precision, durability, and long service life. This right-hand version is built for demanding shop use where stability and adaptability are essential.
- Functions as a U-Shape Square with added elongated holes for flexibility.
- Provides secure positioning with both fixed and adjustable stop options.
- Includes mounting holes for table legs on sizes 500mm and above.
- Constructed with 25mm thick walls for maximum rigidity.
- Plasma nitrided surface increases wear resistance and longevity.
Key Features:
- Offers precise alignment with round and elongated hole options.
- Delivers high strength with heavy 25mm thick steel walls.
- Ensures long-term wear protection with plasma nitrided finish.
- Supports multiple clamping and extension configurations.
- Fully compatible with Siegmund System 28 Metric Series.
Specifications:
- Series: Siegmund System 28 Metric Series
- Length: 500mm (19.69" Inches)
- Width: 200mm (7.87" Inches)
- Height: 100mm (3.94" Inches)
- Material Thickness: 25mm (0.98" Inches)
- Weight: 88.18 lbs. (40 kg.)
- Surface: Plasma Nitrided
Common Uses:
The Siegmund 500x200x100mm Square U-Shape with Elongated Hole Right is widely used as a structural support, adjustable stop, or extension block in advanced welding and assembly setups. Fabricators depend on its borehole and slot combination to enable quick reconfigurations while maintaining precision. Its strength and nitrided durability make it a reliable component for long-term shop performance.
