The Siegmund 2,000x200x100mm Square U-Shape is the longest extension available in the Siegmund System 28 Metric Series. With its extended 2,000mm reach, reinforced plasma nitrided finish, and heavy-duty construction, it provides exceptional stability and support for the largest welding and fixturing setups.
- Built for extreme-length applications requiring maximum rigidity.
- Diagonal hole pattern enables highly flexible clamping and modular layouts.
- 25mm (0.98" Inches) wall thickness ensures strength and long service life.
- Grid lines with 100mm (3.94" Inches) spacing streamline orientation.
- Rear mounting holes allow secure table leg installation for safe support.
- Plasma nitrided treatment offers superior resistance to wear and welding spatter.
Key Features:
- Handles oversized and long-span setups with unmatched stability.
- Provides reliable orientation with integrated 100mm (3.94" Inches) grid lines.
- Delivers durability through plasma nitrided hardened construction.
- Ensures compatibility with Siegmund System 28 Metric Series fixturing.
- Accommodates heavy welds with its 310.85 lbs. (141 kg.) weight capacity.
Specifications:
- Series: Siegmund System 28 Metric Series
- Item No.: 2-280340.P
- Length: 2,000mm (78.74" Inches)
- Width: 200mm (7.87" Inches)
- Height: 100mm (3.94" Inches)
- Material Thickness: 25mm (0.98" Inches)
- Weight: 310.85 lbs. (141 kg.)
- Finish: Plasma Nitrided
Common Uses:
This Square U-Shape is built for fabrication shops that need to extend Siegmund System 28 tables to their maximum span. It provides unmatched stability for large-scale weldments, vertical structures, and multi-table assemblies. Its extended 2,000mm length, reinforced wall thickness, and optional leg support make it indispensable for the heaviest and most complex fabrication projects.
