The Siegmund 2-280360.3.P: 500x400x400mm Square U-Shape Riser Block provides a strong, stable base for heavy structures and large workpieces. Built from 25mm (0.98" Inches) steel and plasma nitrided for hardness, it ensures durability under demanding shop conditions.
- It delivers a rigid platform for table extensions and structural builds.
- Five-sided boreholes and optional diagonal holes maximize clamping flexibility.
- Precision 100mm (3.94" Inches) grid spacing streamlines orientation.
- Mounts securely to tables using connector bolts for dependable alignment.
- Supports use with Siegmund legs and foundation rails for extended setups.
Key Features:
- Engineered for Siegmund System 28 Metric Series with precision 100mm grid.
- Plasma nitriding enhances surface hardness and resistance to wear.
- Five-sided boreholes expand clamping and fixture options.
- Delivers heavy-duty stability for large assemblies and vertical setups.
Specifications:
- System: Siegmund System 28 Metric Series
- Length: 500mm (19.69" Inches)
- Width: 400mm (15.75" Inches)
- Height: 400mm (15.75" Inches)
- Material Thickness: 25mm (0.98" Inches)
- Weight: 388.01 lbs. (176 kg.)
Common Uses:
This Square U-Shape Riser Block delivers stable support for superstructures, heavy workpieces, and precision assemblies. Fabricators use it to extend welding tables, create vertical setups, and secure large-scale components with maximum rigidity and clamping versatility.
