The Siegmund Square U-shape riser block delivers maximum stability and reach for welding setups that require large extensions and strong vertical positioning. Built with plasma nitrided steel, it ensures long-term durability and precision in heavy-duty shop environments.
- Provides a 500x200x200mm (19.69"x7.87"x7.87" Inches) riser block for long extensions and vertical setups.
- Durable plasma nitrided surface resists wear, spatter, and corrosion.
- 25mm (0.98" Inches) wall thickness guarantees rigidity under load.
- Grid lines with 100mm (3.94" Inches) spacing simplify alignment and repeatability.
- Five-sided borehole arrangement with optional diagonal holes enables versatile clamping.
Compatible with connector bolts and legs for use with Siegmund foundation rails.
Key Features:
- Delivers stable long extensions for welding tables and fixtures.
- Hardened plasma nitrided finish extends working life.
- Multiple clamping and positioning options with five-sided and diagonal boreholes.
- Maintains precise orientation with 100mm (3.94" Inches) grid system.
- Seamlessly integrates with Siegmund System 28 Metric Series setups.
Specifications:
- System: Siegmund System 28 Metric Series
- Length: 500mm (19.69" Inches)
- Width: 200mm (7.87" Inches)
- Height: 200mm (7.87" Inches)
- Material Thickness: 25mm (0.98" Inches)
- Weight: 147.7 lbs. (67 kg.)
Common Uses:
This riser block provides extended reach and secure vertical positioning for large-scale welding applications. It supports long table extensions and heavy-duty clamping arrangements, delivering precise alignment and reliable performance. Its hardened surface and rigid construction ensure consistent results in demanding fabrication setups.
