The SiegmundSquare U-shape riser block provides maximum extension and vertical support for large-scale welding projects. Its plasma nitrided surface ensures long-lasting durability, while its robust structure delivers reliable performance under demanding shop conditions.
- Measures 800x200x200mm (31.50"x7.87"x7.87" Inches) for extra reach in welding setups.
- Plasma nitrided finish provides resistance to wear, weld spatter, and corrosion.
- 25mm (0.98" Inches) wall thickness ensures rigidity under heavy loads.
- 100mm (3.94" Inches) grid spacing supports precise orientation and repeatability.
- Five-sided borehole layout with optional diagonal holes expands clamping flexibility.
- Includes mounting holes on the back for attaching table legs when used as an extension.
Key Features:
- Provides long-span extensions and vertical positioning for large welding setups.
- Nitrided surface delivers maximum strength and extended service life.
- Compatible with connector bolts and legs for foundation rail use.
- Five-sided borehole system with 100mm (3.94" Inches) spacing ensures accuracy.
- Integrates seamlessly with Siegmund System 28 Metric Series welding tables.
Specifications:
- System: Siegmund System 28 Metric Series
- Length: 800mm (31.50" Inches)
- Width: 200mm (7.87" Inches)
- Height: 200mm (7.87" Inches)
- Material Thickness: 25mm (0.98" Inches)
- Weight: 218.3 lbs. (99 kg.)
Common Uses:
This riser block supports extended table connections and vertical positioning in large-scale fabrication projects. It delivers stable alignment and durable clamping capability for heavy workpieces, ensuring repeatable accuracy. With its hardened nitrided surface and mounting compatibility, it is built for the most demanding shop applications.
