The Siegmund 2-280392.P: 3,000x200x200mm Square U-Shape Riser Block delivers maximum extension capacity for oversized welding and fixturing applications. With its plasma nitrided surface, it withstands extreme shop conditions, resisting wear and weld spatter while maintaining structural rigidity across its 3-meter span.
- Measures 3,000x200x200mm (118.11"x7.87"x7.87" Inches) for the longest available extension.
- Plasma nitrided surface ensures durability against wear, corrosion, and spatter.
- 25mm (0.98" Inches) wall thickness delivers superior strength and rigidity.
- 100mm (3.94" Inches) grid spacing allows precise orientation and repeatability.
- Five-sided borehole design with optional diagonal holes expands clamping versatility.
- Back-mounted holes support secure attachment of table legs for long-span setups.
Key Features:
- Delivers the maximum reach in the Siegmund riser block series.
- Plasma nitrided surface extends service life under extreme shop conditions.
- Provides precision and repeatability with 100mm (3.94" Inches) grid spacing.
- Five-sided borehole system increases clamping flexibility.
- Integrates seamlessly with Siegmund System 28 Metric Series welding tables.
Specifications:
- System: Siegmund System 28 Metric Series
- Length: 3,000mm (118.11" Inches)
- Width: 200mm (7.87" Inches)
- Height: 200mm (7.87" Inches)
- Material Thickness: 25mm (0.98" Inches)
- Weight: 729.7 lbs. (331 kg.)
Common Uses:
This riser block supports long-span extensions and vertical setups for the largest fabrication projects. It delivers unmatched reach, rigidity, and alignment accuracy for oversized workpieces in heavy-duty welding environments. With its nitrided finish and compatibility with Siegmund table legs, it provides reliable stability and long-term performance.
