The Siegmund Square U-Shape 1,500x200x200mm Premium Light provides maximum extension capacity with a lighter structure, making it easier to handle without compromising rigidity. Its long, 1,500mm reach ensures stable bridging and vertical setups for large-scale projects.
- Constructed from Siegmund Premium Light material, reducing weight by up to 40%.
- Extended 1,500mm (59.06" Inches) length allows large-scale table configurations.
- Five-sided boreholes and optional diagonal hole patterns enable flexible clamping.
- Marked with 100mm (3.94" Inches) grid lines for precise positioning and repeatability.
- Crafted from through-hardened Siegmund X8.7 alloy steel with plasma nitrided finish.
- Weighs 242.51 lbs. (110 kg.) for strong, stable support with reduced handling strain.
Key Features:
- Longest Premium Light riser block for extended welding table setups.
- Lightweight alloy reduces handling fatigue by up to 40%.
- Plasma nitrided finish ensures durability and wear resistance.
- Five-sided borehole design delivers maximum fixturing flexibility.
- Compatible with Siegmund System 28 Metric Series for large-scale assemblies.
Specifications:
- Item No.: 2-800380.P
- Series: Siegmund System 28 Metric Series
- Length: 1,500mm (59.06" Inches)
- Width: 200mm (7.87" Inches)
- Height: 200mm (7.87" Inches)
- Material Thickness: 15mm (0.59" Inches)
- Weight: 242.51 lbs. (110 kg.)
- Material: Through-hardened tool steel, alloy Siegmund X8.7, plasma nitrided finish
Common Uses:
This U-shape riser block extends welding tables for heavy-duty fabrication, bridging long spans or supporting tall vertical fixtures. Its extended, 1,500mm length delivers strength and stability in demanding applications, while its Premium Light design reduces setup strain and improves handling efficiency in the shop. For clamping with 280511 bolts Spacer Ring 800653.1.N is required.
